T-K Junior Tankless Gas Water Heater
Takagi offers Dual Application Hot Water Use in One Small Package

 Creative Energy Technologies Inc:T-K2 Tankless Gas Water Heater
Takagi

Flash Model T-K Jr

Unlimited Hot Water For Any Small Family

The newest tankless water heater in the Takagi family is called the Flash T-K Jr. The Flash T-K Jr operates with high performance in a tiny package. Refinements incorporated into the T-K Jr include a computer modulating gas valve to allow for two simultaneous applications at once.

Despite the small size, the Flash T-K2 has a maximum flow rate of 5.8gpm,  making it  ideal for residential water heating.

The Flash T-K Jr can fit into tight spots that could never accommodate a full size water heater. Weighing in at only 30 lbs, it measures only 20 inches high by 14 inches wide by 6 inches deep. It's small size allows it to be installed in a variety of locations, indoors or outdoors.

The thermal efficiency of the Flash T-K Jr is over 83% using natural gas and 84% on propane gas with low NOx emission to meet AQMD (Air Quality Management District) regulation.

This is far superior to the conventional water heater efficiency. Because the T-K Jr is more efficient, it uses less fuel and is therefore more cost efficient to operate and environmentally friendly.

Technical Specifications/Comparisons Aquastar 125 FX
Gas Type Natural Gas or Liquid Propane SAME
Input BTU Rate NG Min 19,500-Max140,000 LP Min17,000-Max140,000 117,000 - 125,000
Thermal Efficiency NG Max 83% LP Max 84% 80%
Energy Factor NG .83 LP .84 .78
First Hour Rating (DOE) 180gph - based on incoming ground water temp. of 60F and output set at 115F N/A
Dimensions 20in.(H) 14 in. (W) 6in.(D) 29.75in.(H) 18.25in.(W) 8.73in.(D)
Net Weight 30lbs. 52lbs.
Water Connection 3/4in. NPT 1/2in. NPT
Gas Connection 3/4in. NPT SAME
Gas Pressure NG Min 5.0wc-Max10.5wc LP Min 11wc-Max14wc NG MIN. 7WC LP MIN.11WC
Electrical Supply 120V, 0.8A SAME
Water Flow Rate Min 0.75GPM- Max. Flow 5.8 GPM Min 0.75GPM- Max. Flow 3.6 GPM
 Venting 4" Single Wall
Stainless Steel Cat. III
5" Round
Installation Indoor or Outdoor (with optional outside vent cap) INDOOR ONLY
Accessories

Vent Cap Kit
TK-TV04





Wall fitting Flue terminator
TK-TV01
 Creative Energy Technologies Inc: T-K1 Tankless Gas Water Heater For Larger Requirements
Remote Controller
TK-RE02
Adjustable water temperature
from 95°F -167°F.
 Creative Energy Technologies Inc: T-K1 Tankless Gas Water Heater For Larger Requirements
Exhaust Backflow Prevention Kit
TK-TV03
Prevents cold air from freezing the heat exchanger
TK-TV09 Sealed Combustion Conversion Kit.padThe combustion conversion kit converts a regular TK-Jr into a direct vent unit. The unit will then take fresh air from outdoors.

Model Description Price Buy On Line
T-K Jr T-K Junior Tankless Water Heater $771.00 Add to Cart
View Cart

TK-RE02

Remote Controller $149.00
View Cart

TK-TV01

Wall Ventilation Terminator
View Cart
TK-TV09 Sealed Combustion Conversion Kit $68.00
View Cart
TK-TV03 Exhaust Backflow Prevention Kit
View Cart
TK-TV04 Vent Cap Kit for Outside Install $49.00
View Cart
PLU-PTR34 Pressure & Temperature Relief Valve $7.99 Add to Cart
View Cart
P7925 Mineral Manager - Pipe DeScaler $42. Add to Cart
View Cart
Mineral Manger Electronic Descaler for scale and lime deposit build up For customers with hard water, CET recommends the Mineral Manager. This conditioner will prevent damaging lime-scale from building up and clogging your tankless water heater.

Back To CET's Main Tankless Water Heating Page
